Semi Electric Drum Stacker Hydraulic Drum Lifter
Order Semi Electric Drum Stackers. Features C-frame mast, eagle-grip mechanism for upright barrels, optional digital scale, 1450mm lifting height, and 500kg capacity. Request a quote!
Product Overview
The Semi Electric Drum Stacker (widely recognized across logistics hubs and chemical storage facilities as the Motorized Hydraulic Drum Lifting Truck, and specified across Latin American industrial sites as Apilador semielectrico de tambores) is an efficient, battery-powered material handling truck engineered for the vertical lifting, stacking, and transport of upright drums and barrels.
Built with a high-strength C-frame steel mast utilizing specialized rolling technology, this stacker provides structural rigidity and operator safety during elevated transport. Featuring a self-locking eagle-grip clamping head (available in single or double Gator Grip configurations), this 500kg semi electric drum mover securely engages the top rim of steel and plastic drums automatically upon lifting. Available with an optional high-accuracy digital weighing scale, the DT500 range optimizes barrel handling inside warehouses, production plants, and distribution centers.
Advanced Mechanical Engineering & Innovations
Handling upright barrels demands reliable rim clamping, smooth vertical elevation, and secure weight monitoring:
Automated Eagle-Grip Rim Clamping: Features an heavy-duty eagle-grip structure (with optional single or double Gator Grip heads) that clamps onto the top rim of upright drums automatically as the lift frame elevates, ensuring slip-free holding without deforming the drum wall.
Special Rolling C-Frame Steel Mast: Constructed with heavy-gauge C-channel steel rails that provide enhanced structural rigidity and safety when elevating 500 kg loads to maximum height.
Electric Hydraulic Power Pack: Driven by a 1.6 kW hydraulic pump motor and a maintenance-free 100 Ah / 12 V battery unit, delivering smooth, consistent vertical hoisting speeds of 120 mm/s.
Integrated Digital Weighing System (Model DT500-1): Outfitted with an optional digital weighing display offering measurement accuracy up to $\pm 3\%$, enabling inventory check and weight verification during transfer operations.
Compact Turning Radius: Engineered with a tight turning radius (1430 mm for DT500 and 1450 mm for DT500-1) to allow maneuvering in narrow racking aisles and crowded storage bays.
Technical Specifications & Parameter Matrix
Certified performance parameters, battery electrical ratings, dimensions, and net weights for the complete eagle grip vertical drum lifter lineup:
| Model | Load Capacity | Net Weight | Wheel Dimension (Front / Rear) | Inner/Outer Width of Front Leg | Turning Radius | Pump Unit Power | Battery Parameter | Lifting Height | Lifting Speed |
| DT500 | 500 kg | 226 kg | $\text{Ø}80 \times 55 / \text{Ø}150 \times 50\text{ mm}$ | 630 / 810 mm | 1430 mm | 1.6 kW/h | 100 Ah / 12 V | 1450 mm | 120 mm/s |
| DT500-1 (with scale) | 500 kg | 254 kg | $\text{Ø}80 \times 55 / \text{Ø}150 \times 50\text{ mm}$ | 1450 mm | 1450 mm | 1.6 kW/h | 100 Ah / 12 V | 1450 mm | 120 mm/s |
B2B Procurement Note: The front straddle leg design features an inner width of 630 mm and an outer width of 810 mm, allowing the truck to straddle standard pallets for quick pick-and-place operations of 200-liter (55-gallon) drums.
Critical Capacity Management & Drive Dynamics
Plant managers operating the upright drum lifting truck with scale fleet must align truck capabilities with workflow requirements:
Integrated Weighing Functionality: Model DT500-1 incorporates a digital load cell and LED display terminal, allowing facility operators to weigh incoming drum stock and verify filling levels directly on the shop floor without transporting containers to a central floor scale.
Vertical Hoisting Performance: Both models provide a standard 1450 mm lifting height with a 120 mm/s hoisting speed, allowing operators to stack drums two-tier high on storage racks or load them onto standard flatbed trucks with minimal cycle times.
Industrial Applications
Chemical Warehouses & Raw Material Staging: Workers utilize the Apilador semielectrico de tambores to move, stack, and retrieve 55-gallon chemical drums stored on multi-tier pallet racks.
Petroleum Processing & Lubricant Logistics: Distribution personnel deploy the Motorized Hydraulic Drum Lifting Truck to load heavy oil barrels onto transport vehicles and staging platforms.
Pharmaceutical & Coating Manufacturing: Plant operators deploy the c-frame electric battery drum stacker with integrated scale to track inventory weights of raw liquid barrels entering batch production.
Food Processing & Beverage Storage: Facility crews utilize the Semi Electric Drum Stacker to maneuver vertical ingredient barrels through tight storage aisles and processing suites.
